Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Alternate Mfr Part Number | 44039 |
| Body Style | Rectangular |
| Connection Type | QD Integral |
| Diameter, Body | 18 |
| Housing Material | Thermoplastic |
| Humidity | 90% @ 50 C |
| Indicator | LEDs |
| Input Output | Discrete |
| IP Rating | IP67 |
| Light Source | Infrared LED |
| Material, Lens | Acrylic |
| Maximum Operating Temperature | 70 C |
| Measurement Range | 3 m |
| Mechanical Angle | 1 |
| Minimum Operating Temperature | -20 C |
| Mounting Type | M18 Threaded |
| NEMA Rating | NEMA 1 ; NEMA 2 ; NEMA 3 ; NEMA 3S ; NEMA 4 ; NEMA 4X ; NEMA 6 ; NEMA 12 |
| Number of Pins | 4 |
| Operating Temperature, Maximum | 70 C |
| Operating Temperature, Minimum | -20 C |
| Operation | Dark-ON/Light-ON |
| Output | NPN/PNP |
| Response Time | 1 ms |
| Sensing Mode | Through Beam Receiver |
| Series | |
| Supply Voltage | 10-30 VDC |
| Time, Turn-On Delay | 100 ms |
| Type | Through Beam Sensors |
Overview
Mini-Beam SM312 Series Sensors
The SM312 series of photoelectric sensors from Turck Banner are self contained DC operated sensors. This Mini-Beam SM312 series are compact high performance sensors with 18 mm threaded lens, The SM312 Series are ideal for registration mark detection, baggage handling and bottle conveying applications.
