Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Body Material | ABS, Grey |
| Body Style | Cylindrical |
| Cable Length | 2 m |
| Connection Type | Cable |
| Current, Switching | 100 mA |
| Dimensions | 39mm L x M18 x 1 Dia. |
| Indicator | LED Yellow (Output ON) |
| IP Rating | IP67 |
| Light Source | LED, 850 nm |
| Maximum Operating Temperature | 60 C |
| Measurement Range | 6.5 m |
| Mounting Type | M18 Threaded |
| Operating Temperature, Maximum | 60 C |
| Output | NPN/PNP |
| Response Time | 1.0 mSec |
| Sensing Mode | Retroreflective |
| Series | |
| Standards | UL Listed, CE Marked |
| Supply Voltage | 24 VDC |
| Technology | Photoelectric |
| Type | Retroreflective Sensors |
Overview
The PA18C.R... is part of a family of inexpensive general purpose retro-reflective sensors in industrial standard 18 mm cylindrical ABS housing. The sensors are useful in applications where high accuracy detection as well as small size is required. Compact housing and high power LED for excellent performance-size ratio.
Features:
