| Product Attribute | Attribute Value |
|---|---|
| Accuracy | ±0.25% |
| Maximum Operating Temperature | 85°C |
| Maximum Pressure Measured | ±10 PSI (±68.95 kPa) |
| Minimum Operating Temperature | -20°C |
| Mounting Type | PCB Mount |
| Operating Temperature, Maximum | 85°C |
| Operating Temperature, Minimum | -20°C |
| Output | 0.5-4.5 V |
| Output Type | Analog Voltage |
| Port Style | Barbed |
| Port, Type | Male - 0.19" (4.93mm) Tube, Dual |
| Pressure, Operating | ±1 PSI (±6.89 kPa) |
| Series | |
| Supply Voltage | 4.75-5.25 VDC |
| Termination | Through Hole |
Overview
Honeywell SSC Series – TruStability® Board Mount Pressure Sensors | Standard Accuracy, Compensated/Amplified:
Honeywell’s TruStability® High Accuracy Silicon Ceramic (HSC) Series and Standard Accuracy Silicon Ceramic (SSC) Series are piezoresistive silicon pressure sensors offering a digital or analog output for reading pressure over the specified full scale pressure span and temperature range.
These sensors measure absolute, gage, or differential pressures. The absolute versions have an internal vacuum reference and an output value proportional to absolute pressure. Gage versions are referenced to atmospheric pressure and provide an output proportional to pressure variations from atmosphere. Differential versions allow measurement of pressure between the two pressure ports. The TruStability® pressure sensors are intended for use with non-corrosive, non-ionic gases, such as air and other dry gases. Available options extend the performance of these sensors to non-corrosive, non-ionic liquids for pressure ranges above 40 mbar | 4 kPa | 20 inH2O. All products are designed and manufactured according to ISO 9001 standards.
