PRODUCT DETAILS
The highly accurate PT1000 sensor, capable of measuring temperatures within a wide range of -50°C to 300°C, is commonly used in various industrial applications, especially in liquid detection, food monitoring, storage cold chain, industrial boilers, and aquaculture solutions. PT1000 sensors, also known as 1000-ohm temperature sensors, represent the most prevalent type of platinum resistance thermometer.
Feature
- High-performance: anti-interference and long-term stability
- Easy to install: small size, lightweight, easy to install
- Fast response: sensitive to temperature changes and responds quickly
- Wide temperature range: a wide range of -50°C to 300°C
Description
Direct contact temperature is an important indicator in many scenarios, especially in liquid detection, food monitoring, storage cold chain, industrial boilers, and aquaculture solutions. PT1000 can offer a wide range of direct contact temperatures between -50°C to 300°C.
We also provide wireless DTU of PT1000: , which supports a three-wire circuit for PT1000 sensors and allows for the connection of up to three sensors simultaneously. S2107 is a battery-powered IP66 wireless PT1000 temperature sensor, equipped with built-in Bluetooth and APP service for OTA configuration and remote device management.
Seeed also provides the and to help users better manage and check data remotely.
Add 3 PT1000 sensors to S2107:
Application
- Liquid detection
- Food monitoring
- Storage cold chain
- Aquaculture solutions
Specification
Temperature(PT1000) |
|
Measuring element |
RTD platinum resistance Pt1000 |
Measuring medium |
Solid, liquid or gas (compatible with contact material) |
Range |
-50 to 300 ℃ (For other range customization contact , MOQ 300pcs) |
Accuracy |
Class B (@typical ±0.5℃) |
Wire material |
PTFE silver-plated wire (3-wire) |
Probe Enclosure |
304 stainless steel |
Operating Temperature |
-50 to 200℃(Cable); -50 to 300℃ (Probe) |
IP Rating |
IP68 |
Probe length |
4 * 30mm |
Cable length |
3 meters |
ECCN/HTS
HSCODE | 9025191010 |
USHSCODE | 9026104000 |
UPC | |
EUHSCODE | 9013101000 |
COO | CHINA |
